Lancing

Foil Sealer


Automatic aluminum‑foil bottle sealing with 1–4 heads for higher throughput.


View Specs Configure & Quote

  • Automatic film placement & heat sealing
  • 1–4 sealing heads (custom)
  • Up to 300 °C
  • Round/square mouth support
Foil Sealer

Key Features

Works with PP/PE/PET/PS + aluminum foil

Works with PP/PE/PET/PS + aluminum foil

Customizable sealing diameter (50–250 mm)

Customizable sealing diameter (50–250 mm)

Integrated digital temperature control

Integrated digital temperature control

Solid frame with accessible maintenance points

Solid frame with accessible maintenance points

Technical Specifications

Key Parameters

Model
LUFKR2T
Voltage
110 / 220 V
Working Speed
≈ 900–1200 BPH
Heads
1 / 2 / 3 / 4 (custom)
Compatible Films
PP, PE, PET, PS, Aluminum foil

Additional Data

Heating Temperature
0–300 °C
Sealing Diameter
50–250 mm (customizable)
Air Pressure
4–8 kg/cm²
Machine Size / Weight
2500×1000×1500 mm / ≈ 220 kg

Typical Applications

Food & Dairy

Foil seals on jars and tubs

Chemicals

Barrier seal to prevent leaks

Cosmetics

Hygienic tamper‑evident seal
