LANCING Semi-automatic Pneumatic PET Plastic Square Bottle Labelling Machine

Custom-built packaging machinery

LANCING Semi-automatic Pneumatic PET Plastic Square Bottle Labelling Machine

Model LU-TB802 · New · Available to order

£9,995.00

Total price including VAT and standard UK delivery.

Build lead time: 10 weeksThe ten-week build period begins when Lancing receives and accepts your complete, usable product and packaging samples.
Order this machine
  • Configured around your supplied samples
  • Payment by invoice and bank transfer
  • No change-of-mind returns once custom work begins

Machine overview

Parameter

Main Feature

1. labelling is carried out by means of suction and sticking to achieve labelling on the plane of various work pieces, such as cosmetic flat bottles, packaging boxes, plastic cover labelling, etc.

2. Change the labelling mechanism, which can be applied to uneven surface labelling, such as labelling of concave planes and circular planes.

3.Optional matching ribbon printer and jet printer, labelling at the same time print production batch number, production date, expiration date and other information, labelling, one-step completion of coding, greatly improving production efficiency.

4.It need to custom the fixture to apply to the labelling of various irregular work pieces.(please send you bottle or measure your bottle size )

5.We can custom the machine to apply your label and bottle. please contact with us

Technical details

BrandLancing
Model / MPNLU-TB802
Machine ModelLU-TB802
Machine Voltage110/220V 50-60HZ
labelling Accuracy±0.5 mm
labelling SpeedAbout 15-30 pieces/min
Suitable Product20 mm-200 mm*20 mm-150 mm*0.2 mm-120mm(L*W*H)
Label Size20mm-100mm (W) 15-150mm(Bottom paper height)
Label Inner Diameterø76 mm
Label Outer Diameterø300 mm
Machine Size840mm*470 mm*840 mm
Machine Weight48 kg
Package Size920*520*890 mm
Package Weight78 kg

Specifications are indicative and are finalised against the customer's samples and written order specification.

UK delivery includedStandard delivery is included in the displayed price. Installation and commissioning are separate unless stated in the written order specification.
Custom-built: no change-of-mind returnsBecause the machine is built or adapted to supplied samples, it cannot be returned for a change of mind once custom work begins. Statutory rights for faulty, unsafe or misdescribed goods are unaffected.
